Peer Reviewed


Transiliac Lumbar Hernia

Daniel Tran, DO

Department of Internal Medicine, Rowan University School of Osteopathic Medicine/Jefferson, Stratford, New Jersey

James Lee, DO
Department of Emergency Medicine, Rowan University School of Osteopathic Medicine/Jefferson, Stratford, New Jersey

Alan Lucerna, DO
Department of Emergency Medicine, Rowan University School of Osteopathic Medicine/Jefferson, Stratford, New Jersey

James Espinosa, MD
Department of Emergency Medicine, Rowan University School of Osteopathic Medicine/Jefferson, Stratford, New Jersey

Tran D, Lee J, Lucerna A, Espinosa J. Transiliac lumbar hernia. Consultant. 2020;60(3):93-95. doi:10.25270/con.2020.03.00008


An 83-year-old morbidly obese (body mass index, 33.55 kg/m2) woman presented to the emergency department with progressively worsening atraumatic right hip pain for the past week that had made her unable to walk. She had been previously ambulatory with a cane but has since been bedbound. She described the pain as sharp and associated with movement but relieved by lying supine. She denied numbness or paresthesia to her lower extremities, constipation, or urinary incontinence.

History. Her past medical history was significant for coronary artery disease, congestive heart failure, atrial fibrillation (for which she was taking apixaban), hypertension, chronic obstructive pulmonary disease, stage 3 chronic kidney disease, and rheumatoid arthritis. In addition to apixaban, her current medications were albuterol, aspirin, atorvastatin, diltiazem, furosemide, ibandronate, levothyroxine, metoprolol, spironolactone, fentanyl patch, and oxymorphone. Her past surgical history was notable for an L3-L5 laminectomy and fusion with autologous iliac crest bone grafting (ICBG) more than 15 years prior.

Physical examination. Vital signs on arrival were as follows: blood pressure, 171/143 mm Hg; heart rate, 95 beats/min; respiratory rate, 16 breaths/min; temperature, 37.3°C; and oxygen saturation, 94% on room air. On physical examination, her right hip was tender to palpation. No erythema or open wounds were noted. A soft mass protruded from her right posterolateral hip in the right lateral recumbent position.

Diagnostic tests. Right hip and pelvic radiographs were obtained, which demonstrated a large bone defect involving the right iliac wing with associated degenerative arthritic changes (Figure 1).

Fig 1
Figure 1. Pelvic radiograph showing a large bone defect involving the right iliac wing.


Abdominal and pelvic computed tomography (CT) scans revealed a right posterolateral abdominal wall hernia through the deformity of the iliac crest containing nonobstructed colon and ileum (Figure 2).

Fig 2
Figure 2. CT scans showing a right posterolateral abdominal wall hernia through the deformity of the iliac crest containing nonobstructed colon and ileum.


The patient was referred to a tertiary care center for plastics and orthopedic reconstruction surgery.

Discussion. Bone grafts are essential to achieving a solid spinal fusion by encouraging osteoblastic activity and providing a scaffold to guide bone remodeling. The iliac crest in particular is a common site for autologous bone grafting and is still considered the gold standard due to its ease of access to cortical and cancellous bone.1 Nevertheless, ICBG can be associated with significant morbidity, especially when full-thickness tricortical grafts are harvested. Common complications include donor-site pain, hematoma, thigh dysesthesias, pelvic instability, and fracture.2 Gastrointestinal tract herniation, on the other hand, is a much rarer complication with an occurrence rate of 5% to 9%.3,4

Lumbar hernias are rare, with only approximately 300 reported cases in the literature worldwide.5 A small portion of these hernias are postsurgical complications, such as after ICBG for the repair of bone defects in spinal surgery or trauma and the treatment of malunions, nonunions, and tumors. Full-thickness tricortical ICBG involves incising the periosteum to release all layers of the abdominal wall muscles from their insertion point on the iliac crest; an oscillating saw can then be used to harvest the graft. This creates a large defect in the iliac crest, augmenting the risk for herniation of gastrointestinal tract contents through the weakened abdominal wall.6 The hernia can manifest as early as 3 weeks after surgery to 30 years postoperatively.4

Predisposing factors include obesity, female sex, advanced age, structural weakness of abdominal wall musculature, bone harvesting from the middle portion of the iliac crest, and defect size exceeding 4 cm.4,7,8

A minor complication of ICBG involves postsurgical pain at the harvest site. This is the most frequently reported complication, although reported rates are highly dependent on study design and population.8 Abdominal wall hernia, however, is a more concerning complication due to the risk of intestinal obstruction, incarceration, and strangulation. Abdominal contents may protrude through the inferior triangle of Petit, which consist of the latissimus dorsi medially, the external oblique laterally, and the iliac crest inferiorly. Typical clinical features are a semispherical soft bulge that worsens with increased abdominal pressure and that may disappear when lying down.9 A patient with an incarcerated transiliac hernia from coughing due to chronic obstructive pulmonary disease exacerbation had been described.10 Patients may present with varying degrees of pain and discomfort, as well as vomiting, constipation, and obstipation.4

Although cases of herniation through an iliac defect caused by ICBG have been reported, no reported cases of ambulatory dysfunction as the primary presenting symptom currently exist in the literature. Our concerns for an occult fracture prompted pelvic radiography, the results of which demonstrated a large iliac crest defect. Given our patient’s physical examination findings in conjunction with this large bony defect on radiographs, an abdominal and pelvic CT scans were obtained to further delineate the primary pathology and confirm the diagnosis. CT was essential in characterizing the extent, location, and contents of the hernia, which can help surgeons appropriately manage the disease and plan a course of action in the operating room. More importantly, it can assist in excluding incarceration, which occurs in 25% of cases, and strangulation, which occurs in 10% of cases.11 Ultrasonography, while safe and inexpensive, has limited ability to exclude other concomitant conditions, and its diagnostic accuracy is hampered by obesity.12

Nodarian and colleagues even described a case of liver herniation through the bone defect caused by ICBG.13 Management of transiliac abdominal hernias is similar to other hernias and involves primary surgical repair with or without mesh support. Complications of ICBG are probably more prevalent than reported in the literature and are likely underestimated. The diagnosis may be more difficult in obese patients, and patients may present with vague symptoms such as nausea, vomiting, abdominal discomfort, difficulty ambulating, and pain at the surgical incision site. Therefore, a high index of suspicion for graft-site herniation is necessary for patients with history of autologous ICBG.


  1. Canady JW, Zeitler DP, Thompson SA, Nicholas CD. Suitability of the iliac crest as a site for harvest of autogenous bone grafts. Cleft Palate Craniofac J. 1993;30(6):579-58
  2. Seiler JG III, Johnson J. Iliac crest autogenous bone grafting: donor site complications. J South Orthop Assoc. 2000;9(2):91-97.
  3. Forrest C, Boyd B, Manktelow R, Zuker R, Bowen V. The free vascularised iliac crest tissue transfer: donor site complicates associated with eighty-two cases. Br J Plast Surg. 1992;45(2):89-9
  4. Jetaji N, Sorathia Z. Transiliac hernia: a case report with short review of literature. Int J Res Orthop. 2016;2(2):60-62.
  5. Suarez S, Hernandez JD. Laparoscopic repair of a lumbar hernia: report of a case and extensive review of the literature. Surg Endosc. 2013;27(9):3421-3429.
  6. Behairy YM, Al-Sebai W. A modified technique for harvesting full-thickness iliac crest bone graft. Spine (Phila Pa 1976). 2001;26(6):695-697.
  7. Velchuru VR, Satish SG, Petri GJ, Sturzaker HG. Hernia through an iliac crest bone graft site: report of a case and review of the literature. Bull Hosp Jt Dis. 2006;63(3-4):166-168.
  8. Kim DH, Chun YS, Vaccaro AR, Hilibrand AS, Albert TJ. Complications of iliac crest: bone graft and harvesting. In: An HS, Jenis LG, eds. Complications of Spine Surgery: Treatment and Prevention. Philadelphia, PA: Lippincott Williams & Wilkins; 2005;chap 16.
  9. Zhou X, Nve JO, Chen G. Lumbar hernia: clinical analysis of 11 cases. Hernia. 2004;8(3):260-263.
  10. Radais F, Facy O, Ortega-Deballon P. Transiliac hernia. Am J Surg. 2011;201(6):e41-e42.
  11. Martínez Rodenas F, Torres Soberano G, Hernández Borlan R, Moreno Solórzano JE, Llopart López JR. “Iliac hernia,” an original form of ventral hernia that is probably not so uncommon. Cir Esp. 2017;95(10):618-620.
  12. Fontaine V, Villeneuve P-L, Belzile EL, Laflamme M. Hernia through an iliac crest bone graft harvest site: two cases treated differently. J Clin Case Rep. 2016;6(5):1000798.
  13. Nodarian T, Sariali E, Khiami F, Pascal-Mousselard H, Catonné Y. Iliac crest bone graft harvesting complications: a case of liver herniation. Orthop Traumatol Surg Res. 2010;96(5):593-596.
